The Right Elastomer Starts With Your Process
Quality rollers begin at the source — raw materials. Our compounding plant formulates each cover using strict quality control and precise technical and chemical knowledge of every elastomer.
Nine conditions drive every selection.
01
Temperature
02
Pressure
03
Load
04
Speed
05
Friction
06
Chemical exposure
07
Abrasion
08
Required hardness
09
Process medium
A combination of strict quality control, current mixing technology and detailed chemical knowledge of each elastomer goes into formulating compounds that operate at peak efficiency. Every roller is tested against exacting standards — the result is reduced downtime, lower maintenance costs and better process efficiency.
Fourteen families, compared.
Typical strengths are shown below to guide first selection. Exact hardness ranges, temperature limits and chemical compatibility are confirmed per compound and application with our technical team.
Natural Rubber
NR- High resilience and tack
- Good abrasion resistance
- Economical general-purpose covers
Hypalon
CSM- Strong ozone and weathering resistance
- Good chemical and heat resistance
- Durable in oxidising service
EPDM
EPDM- Excellent ozone and weather resistance
- Good performance with water-based media
- Wide general-purpose chemical resistance
Nitrile
NBR- Strong oil and fuel resistance
- Good abrasion resistance
- Common choice for ink and oil contact
Neoprene
CR- Balanced oil and weather resistance
- Good flame resistance
- Dependable all-round performer
Polyurethane
PU- Outstanding abrasion and tear resistance
- Very high load-carrying capability
- Strong solvent and acid compatibility
Carboxylated Nitrile
XNBR- Enhanced abrasion resistance over standard NBR
- Good oil resistance
- Suited to high-wear oil-contact duties
Hydrogenated Nitrile
HNBR- Improved heat resistance over NBR
- Strong oil and chemical resistance
- Good mechanical strength
SBR
SBR- Good abrasion resistance
- Cost-effective general service
- Stable, consistent processing
NBR / PVC
NBR/PVC- Oil resistance with improved ozone resistance
- Good abrasion performance
- Enhanced weathering over plain NBR
Silicone
VMQ- Excellent high-temperature capability
- Superior release characteristics
- Stable over a wide temperature span
EPDM / Silicone
EPDM/VMQ- Blended heat and weather performance
- Good release properties
- Suited to specialised thermal duties
Butyl
IIR- Very low gas permeability
- Strong resistance to polar chemicals
- Good damping characteristics
Viton
FKM- Premium chemical resistance
- Excellent high-temperature performance
- Long life in aggressive media
Elastomer Selection Support
Not sure which compound suits your line? Share your operating conditions and process medium — our team will recommend and formulate the right cover.
